Panel PC công nghiệp IPPC 2111-C11

21.5” TFT FHD 16:9 Heavy Industrial Panel PC 10th Gen Intel® Core™ i Processor P-Cap Screen, DDR4, PCIe Slot Supported

Giá: Liên hệ

Tính năng chính:

Support 35W 10th Gen Intel® Core™ i9/i7/i5/i3/Pentium®/Celeron® processor (Comet Lake-S)
Stylish slim bezel, metal housing with robust aluminum front zero bezel for harsh environment
10 points P-Cap touch with zero bezel flush front design
2 x DDR4 2933MHz memory, up to 64GB (non-ECC)
Dual Intel® GbE LAN ports/DP++/dual USB 3.0
1 x RS232,1 x RS232/422/485 with isolation (optional)
Internal support :
- 1 x mini-PCIe (PCIe x1, USB 2.0, SATA)
- 1 x M.2 3042/3052 Key B (PCIe x1, USB 3.0, USB 2.0)
- 1 x M.2 2242 Key B (USB 2.0, SATA)
24VDC input; support AT/ATX power mode
1 x PCIe x4 expansion

Báo giá sản phẩm

The new 21.5” fanless panel PC IPPC 2111-C11 is equipped with a high-performance 10th Gen Intel® Core™ i9/i7/i5/i3 socket-type CPU platform, intended for versatile industrial applications. IPPC 2111-C11 has a narrow border touch screen and a LED backlight LCD panel with 1920x1080 (FHD) resolution. The front panel which adopts a flush, narrow border design and complies with the IP66 standard to make it perfectly fit in industrial applications.

IPPC 2111-C11 contains dual Gigabit Ethernet connectors, one mini-PCIe slot, and an M.2 slot to support multiple networks of LAN/WLAN/WWAN (5G). In addition, it can hook a 2nd display via DP++ for dual independent display, one adjustable RS232/422/485 port with isolation, and provides a PCIe x4 for add-on card expansion.

Panel	LCD size: 21.5”, 16:9 LCD interface: LVDS Resolution: FHD 1920 x 1080 Luminance: 250cd/m² Viewing angle: 89 (U), 89 (D), 89 (L), 89 (R) Backlight: LED
Touch	Ten points P-Cap (projected capacitive touch) Light transmission: 90±3% Interface: USB Anti-scratch surface: 7H hardness
System	CPU (optional): support 10th Gen Intel® Core™ i processor family, LGA 1200 socket type, max 35W - 10th Gen Intel® Core™ i9-10900TE (20M Cache 2.0GHz up to 4.5GHz) - 10th Gen Intel® Core™ i7-10700TE (16M Cache 2.0GHz up to 4.4GHz) - 10th Gen Intel® Core™ i5-10500TE (12M Cache 2.3GHz up to 3.7GHz) - 10th Gen Intel® Core™ i3-10300TE (8M Cache 2.3GHz up to 3.6GHz) - 10th Gen Intel® Pentium® G6400TE (4M Cache 3.2GHz) - 10th Gen Intel® Celeron® G5900TE (4M Cache 3.0GHz) BIOS: AMI BIOSIntel® PPT (fTPM) support; TPM IC (optional) System chipset: Intel® H420E PCH System memory (optional): 2 x 260-pin DDR4 SO-DIMM socket, support up to max 32GB DDR4 2933MHz (non-ECC) Storage device: - 1 x M.2 2242 Key B - 1 x mini-PCIe - 1 x Hard drive tray
Rear I/O	2 x DB9 for COM1&COM2 - COM1: RS232 - COM2: RS232/422/485 auto flow control (isolation) 2 x USB 3.1 ports (900mA per each) 1 x DP++2 x Intel® I210-IT GbE LAN ports; support WoL, teaming and PXE 1 x 2-pin remote power on/off switch24V DC input
Expansion Slot	One PCIe x4 expansion slot: FHFL, 40W max 1 x mini-PCIe for Wi-Fi/mSATA 1 x M.2 3042/3052 Key B for 5G/Wi-Fi 1 x Nano SIM card onboard
Power Requirements	AT/ATX power mode (default: ATX power mode) Power input: +24V DC Power adapter: optional AC to DC power adapter (24V DC, 120W)
Dimensions	549.2mm (W) x 345.8mm (D) x 73.6mm (H)
Construction	Aluminum and metal chassis with fanless design
Environment	Operating temperature: - Ambient with air flow: 0°C to 50°C - Storage temperature: -20°C to 75°C Relative humidity: 10% to 90% (non-condensing) Shock protection: - HDD: 20G, half sine, 11ms, IEC60068-2-27 - M.2: 50G, half sine, 11ms, IEC60068-2-27 Vibration protection with SSD&M.2 condition: - 2.0Grms @ random condition, 5~500Hz, 1hr/axis (M.2/ SSDoperating)
Certifications	CE approval- EN61000-6-2- EN61000-6-4 FCC Class A
OS Support	Windows 10 64-bit Windows 11 64-bit
Weight Information	9 kg

Barebone
IPPC 2111-C11 (P/N: 10II0211100X0)
21.5” TFT FHD 16:9 heavy industrial panel PC 10th Gen Intel® Core™ i processor support, P-Cap screen, DDR4, PCIe slot supported

Others
24V, 60W AC/DC power adapter w/o power cord
(P/N: 7400060061X00)
24V, 120W AC/DC power adapter w/o power cord
(P/N: 7400120029X00)
