IFA 2610

CoreFort™ industry Firewall, 3 ports VPN Router with Rugged Design

Giá: Liên hệ

Tính năng chính:

Stateful (L4) packet firewall
Intrusion prevention (IPS)
SSL VPN secure remote access
DI/DO support
Serial gateway (RS485)
Versatile logging & report system

Báo giá sản phẩm

Datasheet (PDF)

The CoreFort™ industry firewall series is a fully integrated industry 3 ports firewall router with VPN function. The fully equipped, broadband-capable firewall router offers a stateful packet inspection firewall, denial-of-service(DoS)/distributed denial-of-service(DDoS) protection and intrusion prevention, portscan detection, and real-time alerts. It gives additional protection for machinery and equipment installed on the secure side of the firewall. Equipped with SSL VPN functions, the CoreFort™ industry firewall provides a remote access infrastructure to secure connections, and helps machine builder/system integrator to design easily maintained systems. Furthermore, its tough fully-rugged design is ideal for harsh environment applications.

Pairing VPN capabilities, the CoreFort™ industry firewall series is an ideal endpoint connectivity and security solution for industrial automation, process control, energy and medical instrument remote management application.

Network Security	Stateful packet firewall Intrusion detection/prevention (IDS/IPS) Multiple public IPs SNMP support (V1/V2/V3) VoIP/SIP support Portscan detection DoS and DDoS protection SYN/ICMP flood protection DNS proxy/routing
Multi-WAN/Failover	Supports multiple Uplinks/WANs: Ethernet (Static/DHCP), PPPoE Automatic WAN Uplink Failover Monitoring of WAN Uplinks
Traffic Shaping	Bandwidth Management
User Authentication	Active Directory /NTLMLDAPLocal
Network Address Translation	Destination NATIncoming Routed TrafficOne-to-One NATSource NAT (SNAT)IPSec NAT Traversal
High Availability	Hot Standby (active/passive)Node Data/Configuration Synchronization
Bridging	Firewall Stealth ModeOSI-layer 2 firewall-function Spanning treeUnlimited bridges Unlimited interfaces per bridge
VPN (Virtual Private Network)	IPsec - Encryption: 3DES, AES 128/256-bit,MD5, SHA1 - Diffie hellman (2, 5, 14, 15, 16,17,18) - Authentication: Pre-shared key, RSA keys X.509-certificates IKEv1, L2TP - DPD (dead peer detection) - NAT Traversal - Compression - PFS (perfect forward secrecy) - VPN: site-to-site - VPN: client-to-site (road warrior) - Integrated certificate authorityTrue SSL/TLS VPN (OpenVPN) - Encryption: DES, 3DES, AES 128/192/256-bit, CAST5, Blowfish - Authentication: Pre-shared key, X.509-certificates, certification authority, and local - Support for VPN over HTTPS proxy (OpenVPN) - PPTP passthrough - VPN: site-to-site - VPN: client-to-site (road warrior) - VPN: client for Microsoft Windows, Mac OS X and Linux - Multiple logins per user - VPN failover
Services	Event notification & handling NTP (Network Time Protocol) DHCP Server SNMP Server DynDNS
Logs and Reports	Customizable Real-time Dashboard Live Log Viewer (AJAX-based) Detailed User-Based Web Access Report Network/System/Performance Statistics Rule-based logging settings (Firewall Rules) Syslog: Local or RemoteopenTSA trusted time stamping
Management	Easy Web-based Administration (SSL) Secure Remote SSH/SCP Access Centralized Management (via SSL)
Updates and Backup	Centralized updates through CoreFort™ network Scheduled backup Encrypted backups via e-mailInstant recovery/backup to USB stick
Routing	Static RoutesSource-based RoutingDestination-based RoutingPolicy-based Routing (based on interface, MAC, protocol, or port)
Hardware Specification	1 x 10/100/1000 Base-T Ethernet WAN 2 x 10/100/1000 Base-T Ethernet LAN 1 x USB 1 x DI/DORS-232/422/485microSD 4GB
Physical and Power	DIN rail/wall mount (optional) Fanless Dimension(H x W x D): 167 x 59 x 140mm Weight(G.W. Kg):1.90Kg IP30 Terminal block,24V DC
Environmental Specification	Operating Temperature 0°C ~ 60°C (32°F ~ 140°F) Storage Temperature -20°C ~ 70°C(-4°F ~ 158°F) Humidity: 5% ~ 95%, non-condensing
Certification	Safety: UL 508FCC/CE/RoHS
Package Content	IFA 2610 x 1QIG x 1 Power Input 5.08mm Terminal Block x 1 DI/DO Terminal Block x 1

IFA 2610 (P/N: 10IF0261000X0)
Industry firewall 3 ports VPN router (3 years service & maintenance)

Manual
Date	Description	Version	OS	Download
2015-05-21	Quick Reference Guide	1.1	Windows
2016-02-25	User Manual	1.2	Windows
