IFA 3610

CoreFort™ Industry Firewall, 5 ports VPN Router with Wide Temperature Range

Giá: Liên hệ

Tính năng chính:

Stateful (L4) packet firewall
Intrusion prevention (IPS)
SSL VPN secure remote access
DI/DO support
Serial gateway (RS485)
Wide temperature range, up to 70°C (158°F)

Báo giá sản phẩm

Datasheet (PDF)

The CoreFort™ industry firewall series is a fully integrated industry multi-port firewall router with a VPN function. The fully equipped, broadband-capable firewall router offers a stateful packet inspection firewall, denial-of-service(DoS)/distributed denial-of-service(DDoS) protection and intrusion prevention, portscan detection, and real-time alerts. It gives additional protection for machinery and equipment installed on the secure side of the firewall. Equipped with SSL VPN functions, the CoreFort™ industry firewall provides a remote access infrastructure to secure connections, and helps machine builder/system integrator to design easily maintained systems. Furthermore, its tough fully-rugged design is ideal for harsh environment applications. With a wide temperature range up to to 70°C (158°F) degree, it offers reliable communication networks in extreme temperature conditions.

Pairing VPN capabilities, the CoreFort™ industry firewall series is an ideal endpoint connectivity and security solution for industrial automation, process control, energy and medical instrument remote management application.

Network Security	Stateful packet firewall Intrusion detection/prevention (IDS/IPS) Multiple public IPs SNMP support (V1/V2/V3) VoIP/SIP support Portscan detection DoS and DDoS protection SYN/ICMP flood protection DNS proxy/routing
Multi-WAN/Failover	Supports multiple Uplinks/WANs: Ethernet (Static/DHCP), PPPoE Automatic WAN Uplink Failover Monitoring of WAN Uplinks
Traffic Shaping	Bandwidth Management
User Authentication	Active Directory /NTLMLDAPLocal
Network Address Translation	Destination NAT Incoming Routed Traffic One-to-One NATSource NAT (SNAT) IPSec NAT Traversal
High Availability	Hot Standby (active/passive)Node Data/Configuration Synchronization
Bridging	Firewall Stealth ModeOSI-layer 2 firewall-function Spanning treeUnlimited bridges Unlimited interfaces per bridge
VPN (Virtual Private Network)	IPsec - Encryption: 3DES, AES 128/256-bit,MD5, SHA1 - Diffie Hellman (2, 5, 14, 15, 16,17,18) - Authentication: Pre-Shared Key, RSA Keys X.509-certificates IKEv1, L2TP - DPD (Dead Peer Detection) - NAT-Taversal - Compression - PFS (perfect forward secrecy) - VPN: site-to-site - VPN: client-to-site (road warrior) - Integrated certificate authorityTrue SSL/TLS VPN (OpenVPN) - Encryption: DES, 3DES, AES 128/192/256-bit, CAST5, Blowfish - Authentication: Pre-shared key, X.509-certificates, certification authority, and local - Support for VPN over HTTPS proxy (OpenVPN) - PPTP passthrough - VPN: site-to-site - VPN: client-to-site (road warrior) - VPN: client for Microsoft Windows, Mac OS X and Linux - Multiple logins per user - VPN failover
Services	Event notification & handling NTP (network time protocol) DHCP server SNMP server DynDNS
Logs and Reports	Customizable real-time dashboard Live Log Viewer (AJAX-based) Detailed user-based web access report Network/system/performance statistics Rule-based logging settings (firewall rules) Syslog: local or remote OpenTSA trusted time stamping
Management	Easy web-based administration (SSL) Secure remote SSH/SCP access Centralized management (via SSL)
Updates and Backup	Centralized updates through CoreFort™ network Network Scheduled backup Encrypted backups via e-mailInstant recovery/backup to USB stick
Routing	Static Routes Source-based Routing Destination-based Routing Policy-based Routing (based on interface, MAC, protocol, or port)
Hardware Specification	1 x 10/100/1000 Base-T Ethernet WAN 4 x 10/100/1000 Base-T Ethernet LAN 1 x USB 1 x DI/DORS-232/422/485 microSD 4GB
Physical and Power	DIN rail/wall mount (optional) Fanless Dimension (H x W x D): 167mm x 59mm x 140mm Weight(G.S. Kg):1.90Kg IP30Dual power input 24VDC
Environmental Specification	Operating Temperature: -20°C ~ 70°C/-4°F ~ 158°F Storage Temperature: -40°C ~ 80°C/-40°F ~ 176°F Humidity: 5% ~ 95%, non-condensing
Certification	Safety: UL 508F CC/CE/RoHS
Package Content	IFA 3610 x 1QIG x 1 Power Input 5.08mm Terminal Block x 2 DI/DO Termina Block x 1

IFA 3610 (P/N: 10IF0361000X0)
Industry firewall 5 ports VPN router (3 years service & maintenance)

Manual
Date	Description	Version	OS	Download
2015-05-22	Quick Installation Guide	1.1	Windows
2016-02-25	User Manual	1.2	Windows

Software
Date	Description	Version	OS	Download
2014-12-11	HengeVPNDialer	1.0
