nROK 1030

1 x 260-pin DDR4 SO-DIMM socket support 3200MHz up to 32GB default 2666MHz, 4GB

With In-Band ECC (IBECC)

1 x HDMI 1.4b up to 3840 x 2160@30Hz

1 x VGA port 1920 x 1200@60Hz

1 x 2.5” SATA 3.0 internal drive bay (9.5mm)

1 x mSATA slot (occupied mini-PCIe slot)

1 x Full size mini-PCIe socket (USB 2.0, PCIe 3.0/SATA 3.0)

1 x M.2 2230 Key E socket (USB 2.0, PCIe 3.0 x2)

1 x M.2 3042/3050/3052 Key B socket (USB 2.0, USB 3.2 Gen 2) for LTE/5G NR module with 2 x external micro-SIM

1 x Default U-blox NEO-M9N GNSS module for GPS+QZSS/Glonass/Galileo/Beidou

Optional M8U modules with dead reckoning available

1 x 3D accelerometer and 3D gyroscope

6 x LED indicators (including 1 x programmable LED)

1 x USB 3.2 Gen 2 type A (5V/0.9A)

1 x USB 2.0 type A (5V/0.5A)

2 x Externally accessible micro-SIM card sockets with cover

1 x Reset button

1 x Power button

1 x DB9 (COM1) for full RS232/422/485

1 DB9 (AUDIO) for 1 x Mic-in, 1 x Line-out

2 x LAN M12 X-coded, 10/100/1000/2500 Mbps

2 x RP-SMA connector holes for WLAN

1 x SMA connector for GNSS

1 x HDMI

1 x VGA

1 x DB9 (COM2) for full RS232/422/485

1 x DB15 (CAN/DIO)
- 1 x Isolated CANBus 2.0B
- 5 x DI and 4 x DO
- Power in for DIO isolation, 9~36VDC

1 x M12 5-pin A-coded DC input with ignition 24 VDC, non-isolation

1 x Connector (4 x 2) for 12VDC/2A output, reset, power button, RS232 (Tx/Rx)

4 x SMA connector holes for WWAN

1 x Ground connector

Power input 24VDC w/o isolation

Cranking voltage: 6V~9V (< 30 seconds)

Reverse protection, OCP & UVP

Selectable boot-up & shutdown voltage for low power protection of software

Setting 8-level power on/off delay time by software10~255 seconds WDT support, setup by software

SDK (Windows/Linux) including utility and sample code

Operating temperatures
- EN 50155, class OT4 (-40°C~70°C), 85°C for 10 minutes (w/ 6W TDP CPU, industrial SSD) with air flow

Storage temperatures: -40°C to 85°C

Relative humidity: 90% (non-condensing)

Vibration (random)
- 2g@5~500 Hz (in operation, SSD)

Vibration (SSD)
- Operating: MIL-STD-810H, Method 514.8C, Procedure 1, Category 4, common carrier US highway truck vibration exposure
- Storage: MIL-STD-810H, Method 514.8E, Procedure 1, Category 24, minimum integrity test

Shock (SSD)
- Operating: MIL-STD-810H, Method 516.8, Procedure I, functional shock=40g
- Non-operating: MIL-STD-810H, Method 516.8, Procedure V, crash hazard shock test=75g

CEFCC Class A

EN 50155: 2017
- Ambient temperature EN 50155, Class OT4 (-40°C~70°C), 85°C for10 minutes
- Interruptions of voltage supply class S1
- Supply change over class C1, C2
- EMC EN 50121-1: 2017, EN 50121-3-2: 2016+A1: 2019
- Environment EN 60068-2-1, EN 60068-2-2, EN 60068-2-30
- Shock and vibration IEC 61373 Class B
- Protective coating class PC1 (PC2, by request)

EN 45545-2: 2020
